Active Directory

Update UPN from AD to Azure AD

When there was a name change in Active Directory (AD), we used to update the Universal Principal Name (UPN) in AD, then separately run the Set-MsolUserPrincipalName command to update Azure AD to the same UPN. Except, it no longer worked – I was now getting an ‘Access Denied’ message.

When trying to update the UPN via the Microsoft 365 admin center, it would correctly advise that the object was homed in AD, so changes needed to be made there. Except, they were, and Azure AD Connect was even reporting that it had seen the update and sent it off to Azure AD, no errors.

After some investigation, I found that there is now an option to allow ‘Synchronize userPrincipalName updates‘ which is off in older tenants. To check and update this:

In PowerShell, first install and connect to MSOLService. Then to check the status if UPN updates will sync and update:

Get-MsolDirSyncFeatures -Feature SynchronizeUpnForManagedUsers

If it’s $true, you’re already set. If it’s $false, update the value to $true with this command:

Set-MsolDirSyncFeature -Feature SynchronizeUpnForManagedUsers -Enable $true

In my testing, running another Azure AD Sync (both delta and full) did not resolve any already updated UPNs. I had to change the UPNs to a temporary value, sync, then change them back to the original value I wanted, and sync again. The update was instant in Azure AD once the sync had run each time.

Azure AD Password Protection Setup Summary

Update 27th November 2023:
The below information may be a bit dated now, so please refer to the lastest official guide here: https://learn.microsoft.com/en-us/entra/identity/authentication/howto-password-ban-bad-on-premises-deploy

Original Post:
Microsoft have a nice way of preventing the use of bad passwords. Yes, all passwords are bad, but some are worse than others :)

Azure Active Directory Password Protection is a service that looks at password changes and blocks passwords it deems as weak. This could be from checking it’s an easy password to break using a dictionary attack, or other easily guessable variants. It leverages Microsoft online services to do so, which requires some setup and agents installed on the on-premises environment.

Microsoft’s documentation for this is detailed and fairly easy to follow, but I thought I’d do a quick rundown.

Installing the agents:

  • There are two agents – the ‘Azure AD Password Protection DC agent’ and the ‘Azure AD Password Protection proxy service’. Both can be downloaded here.
  • The ‘Azure AD Password Protection DC agent’ needs to be installed on all Domain Controllers (DCs), but the ‘Azure AD Password Protection proxy service’ only needs to be installed somewhere once. You CAN install it on a Domain Controller, and you can install it on ALL Domain Controllers, but Microsoft highlighted this as a potential security risk allowing any DC internet access. At least two installs of this is recommended for redundancy.
  • The ‘Azure AD Password Protection proxy service’ can’t be installed alongside (on the same server) as ‘Azure AD App Proxy Service’ – which is probably the same utility server you’d think of putting this on.
  • After installing the ‘Azure AD Password Protection proxy service’ you’ll need to run a few PowerShell commands to register it with global admin rights – you don’t need to create a service account for this, it’s just a one time registration process.

    The commands are:

    Register-AzureADPasswordProtectionProxy -AccountUpn ‘[email protected]
    (run this on each install)

    Register-AzureADPasswordProtectionForest -AccountUpn ‘[email protected]
    (run this after the first install only)
  • Installing the ‘Azure AD Password Protection DC agent’ is easier again, but will need a reboot of the DC to start working.
  • Both clients automatically update themselves.

Configuring in Azure Active Directory

  • You’ll need to enable on-premises Azure Active Directory Password Protection on the Azure AD portal – that link should take you right to ‘Password Protection’ but it’s located under Azure Active Directory > Security > Authentication methods > Password protection.
  • Start with ‘Audit mode’ rather than ‘Enforced Mode’ so you can get an idea of how many users might get affected by this change, and allow you to communicate this out before forcing.
  • You can also add custom banned passwords which might include your company name and common terms in your business and industry, to ensure easily guessed passwords aren’t used.

There are other catches to this, like making sure your domain is using DFSR rather than FRSR so please go through the official documenation carfeully.

Once set up, you can either read through the logs on a DC, or run this PowerShell command on each DC to see the results.:

Get-AzureADPasswordProtectionSummaryReport

You’ll need to either wait for users to change their passwords, or do some yourself and work out which DC the changes were done against. These stats will give you an idea of how many ‘failures’ were audited, so you can decide how much of a user impact enforcing the policy will be.

You could of course ship these event viewer logs to a central repository, but the service should just do it’s thing and just block users from setting a new password that’s really bad.

Conditional Access Baseline Policies Out, Security Defaults In for Azure Active Directory

Something I stumbled across today – it appears that Microsoft has decided to abandon Baseline Protection Policies, and replace them with a single ‘on/off’ switch called ‘Security Defaults’

Baseline Protection policies (also called Baseline Policies, it seems both terms have been used) were in preview, and were a pre-canned set of policies based on Microsoft recommendations on standard security settings that should be in place – such as forcing any administrator account to use MFA at each sign in, and blocking legacy authentication.

Here’s what the Conditional Access page currently shows. There might be something wrong with the detection though, as I clearly have a Baseline Policy enabled:

It’s not difficult to recreate the Baseline policies, so I’d suggest migrating off of them now while they’re still functional – you don’t want to be left in a state where you didn’t realise MFA for admins was now not being forced.

The replacement Security Defaults option can be found by going to Azure Active Directory > Manage – Properties > Manage Security Defaults (it’s not in the Conditional Access area):

Before flipping this switch to ‘On’, you’ll need to have a really good read of the documentation. There’s a lot this option does, and may break many environments who aren’t ready for this – such as making sure you have no Legacy Authentication requirements, and that all users will register for MFA within 14 days or be blocked from sign-in until they register.

Although I can see this option being turned on by an uninformed administrator and causing some chaos, I like the idea of this. It means a new tenant can now have a single option to start with to implement several critical aspects to protect the tenant against attacks – right now there’s a lot you need to go through to lock it down, and especially for a small business who doesn’t have the time or resources to do this as well as a larger one, a single on/off switch solves a lot of security problems.

Security Defaults is also available to all customers on all tiers – Azure AD Free tier, which means those who have basic needs can now be protected in several ways they weren’t able to do via Conditional Access before.

Security Defaults isn’t listed as being in Preview as far as I can tell, so it may be an option that’s just rolled out and a ready to go. I am guessing there’ll be a bit of kickback around this being a single option that has no other configurable options in it, so we’ll have to wait and see if the product changes, or Microsoft’s vision of a security toggle stays as their goal.

Exchange Online Migration Clears ‘Recent’ Document Lists from Word and Excel

I struggle to fit these issues into a short but descriptive headline sometimes :)

This issue is a little strange. If you didn’t know any better (like me), you’d expect the location of a user’s mailbox to have no impact whatsoever on the function of ‘Recent’ document history inside of Microsoft Excel and Word, but it actually does.

I found this out the hard way of course, when a couple of staff mentioned their recent lists had disappeared and it co-coincided with their Exchange on-prem to Exchange online migration.

After some digging, I came across this Reddit post:
Users losing Recent Documents lists in Office 2016 due to upgrade to ADFS. It’s the same problem with a slightly different root cause, and goes into a much deeper technical explanation than what I’ll do here.

The short of it is that the Office applications detect what sort of login you’re using – if it’s Active Directory (AD) or Azure Active Directory (AAD). When that state changes, it uses a different registry path for a few things, including those recent documents.

Without knowing for sure but based on my testing, it must be doing some check to see if the associated account’s mailbox is in Exchange Online or not – and if not, it considers it an AD account. It doesn’t matter if you already have the users in Azure AD, Single Sign on and all that other good stuff set up – the single change of changing the mailbox location to online triggered the change for me.

For an AD account, the history paths are saved in the registry here:

HKEY_CURRENT_USER\SOFTWARE\Microsoft\Office\16.0\Word\User MRU\AD_1234567890 (the number on the end is some sort of unique GUID).

For an Exch account, it’s in this slightly different path:

HKEY_CURRENT_USER\SOFTWARE\Microsoft\Office\16.0\Word\User MRU\ADAL_1234567890 (again, unique GUID at the end).

In case you were wondering, MRU stands for ‘Most Recently Used’. AD is to do with on-prem Active Directory, and ADAL is (according to that reddit post) Azure Active Directory Authentication Library.

Also note the example above is for Word, there’s corresponding paths for other Office applications such as Excel.

There’s two subkeys below this key, one for File MRU and the other Place MRU.

The good news on hitting this scenario is that the values can just be exported, the path changed and re-imported. To do this, via regedit find the registry key that has the values you want (probably the AD one) and right click > export.

Find the file you exported and use notepad to do a find and replace on all the entires for AD_1234567890 and replace to the new value (which you can find from just looking in the registry).

Now, re-import the registry file and you’ll have all the recent document paths restored.

This should only be a one time problem for migrations, and only for people who had a bunch of document paths saved in there and can’t find where they are easily.

Users Managing Email Groups and Exchange Online

For a very long time, users have been able to manage email group members via the Outlook client. Going into the Address Book, finding the group in the Global Address list, going into Properties and choosing ‘Modify Members’:

From there, someone can add or remove members as long as they’d been added to the “Managed By” field against the object in Active Directory, as well as ticking the box “Manager can update membership list” below it.

Easy! Except, that no longer works if the user is in Exchange Online, and the Email Group is from on-premises AD rather than Azure AD/Office 365. It’s not supported. This problem has been around for a while, back in 2015 Perficent wrote about this same topic. The options given for managing these groups are:

  • Exchange Admin Center
  • Exchange Management Console
  • Exchange Management Shell

None of those are what you want your standard users touching in my opinion – although you can give someone access to the Exchange Admin Center and only see the distribution groups they own – but for me, I’m still on Exchange 2010 so this isn’t an option.  This leaves you with a few options:

1. Change all your email groups to Cloud based groups. If this makes sense for you, doing this will let the manager of a cloud based group add/remove members via the Outlook Address Book.
You can also look at changing distribution groups over to Office 365 Groups (which are also cloud based), which give a whole bunch of different features beyond a what a distribution group can do, while giving the same standard DG experience.

2. Make all requests come through to IT so you can make the changes yourself. Not great for anyone involved, as it’s double/triple handling something where the user could quickly do it themselves.

3. Create Dynamic Distribution Groups and let automation do it’s thing – which will work for some, but exceptions to rules and the inability to see who’s in a group can make this frustrating for some.

4. Provide another way for staff to change group members themselves.

I’ve gone with option 4 – as I’m a big fan of Adaxes which I’ve written about a few times on my blog before, and they have a nice way of giving users a web interface that only lets staff manage the groups they’re the owner of.

There’s other ways to do this as well of course and other 3rd party solutions that can expose ways of adding/removing members of a on-premises distribution group – but remember there could be up to a half hour delay in syncing the change from AD to AAD via Azure AD Connect. If possible, look at adding a trigger at the end of a group change to do a delta sync:

Start-ADSyncSyncCycle -PolicyType Delta

That’ll be the quickest way to get the change up quickly, as staff may be used to the change working immediately.

There’s a lot to consider on how you’ll manage this, so make sure it’s sorted before you migrate – or expect a lot more tickets going through your helpdesk.
