Windows

HEIC and HEIF Files Can’t Be Viewed on Windows 10

If you haven’t come across these file formats already, you probably will soon. Created by the Moving Picture Experts Group (MPEG) and adopted by Apple amongst others, it’s looking like a replacement for the old JPEG image format.

The format was added in iOS11 and created when doing things like taking a photo. Early on the files were being converted back to JPEG in many situations, including OneDrive Photo Roll syncs.

I expect something else has changed recently, as I’m seeing the files turn up over email from other parties where I’d never seen them before. If I find out more I’ll update this post.

.HEIC and .HEIF files ‘appear’ to be the same thing, but at this stage I can’t clearly find information explaining if there’s a difference, and if so what that is.

These files can’t be natively opened on Windows 10 or earlier, but there’s a few options you have to view them.

OneDrive

If you have access to OneDrive or OneDrive for Business (which doesn’t take much, a free Microsoft account will do), you can copy these files into OneDrive, right click and ‘View Online’. Via your browser, you can then view the image in OneDrive without any extra software required. However, Microsoft documentation currently does not list the formats as being supported, and I’m also asking questions about this in a few areas. (Update 3rd March 2020 – Microsoft updated this page after I asked :) )

Windows 10

The native Photos app was supposed to have support for this as per these Insider Build notes. I’ve tested on a few different PCs including a fully patched standard Microsoft build laptop, and Photos doesn’t recognise the files. I’ve been told the support of the files needs the two Windows Store apps, and that matches my testing:

HEIF Image Extensions

HEVC Video Extensions from the Device Manufacturer

Both are created by ‘Microsoft Corporation’ so they’re not third party, and both are free. Once installed, HEIC and HEIF files work everywhere I’ve tried, including in the native Photos app.

There is also a paid HEVC Video Extensions version from Microsoft that costs $1.45AU, I’m not sure why you’d need this one over the one ‘from the Device Manufacturer’.

Frustratingly, the ‘HEVC Video Extensions from the Device Manufacturer’ app doesn’t seem to be available to add in Windows Store for Business, but the HEIF Image Extensions is. I’m asking around to try and have that resolved, if I can find someone to listen to me :) (Update 3rd March 2020 – this probably won’t change anytime soon for licensing reasons)

Converting

One final option is to convert a HEIC to JPEG. Here’s a quick guide using Linux via a Debian WSL image, installed from the Microsoft Store (thanks Purana for the tip!)

I’ve got a lot of unanswered questions in the above, but hoping this at least helps others that might get stuck in finding a working solution in the meantime.

How to Automate FTP Uploads with PSFTP

Many vendors and companies still transfer data via FTP. It could be transactional data, user data, or a myriad of other things. Hopefully they’re using SFTP or FTPS (which are different ways of achieving secure FTP transmissions) rather than FTP, for similar data transfer security reasons on HTTP vs HTTPS.

A common use case I come across, is user management. Uploading basic user data like names, email addresses and employee numbers so a vendor can update records in their cloud based product for your staff to use. If you’re using a cloud service and don’t have user automation sorted – then ask them how you can achieve it – it’s much more enjoyable to set up automation, than do repeating mindless tasks.

Assuming you have details on what to send and where, you’ll need to work out how to automate FTP uploads. Note that this is a much less secure method – you’re saving the password in plain text. Alternatives do exist such as what’s demonstrated in this YouTube video below using a Public Key and Private Key Pair, but require the ability to create a .ssh folder on the FTP server. I’d rather do it this way:

Getting the other end to do what you want isn’t always possible in the real world, so you need to consider the risks if you need to save a password in plain text somewhere (saved in a Scheduled Task as you’ll see below). They’re obtainable if someone can get onto the server (or a backup of the server, or connect to Task Scheduler remotely), which should be heavily locked down anyway, and the password for this might be saved in a password database those same staff members have access to anyway.

If those credentials were obtained by another party, what could they do? If the FTP site cleans up the data instantly that’s uploaded, then they could potentially upload whatever they wanted. Look at a worst case and decide if you’re comfortable with having the account credentials saved this way, or need to find another approach.

Again, consider these risks, try to implement the most secure method you can, and raise any concerns with management/your boss. Assuming this is a scenario where you can’t do it more securely:

Instructions

First, you’ll need software. I use PSFTP – part of PuTTY, a free and open source solution. Download the full installer, as there’s a few components of PuTTY we need.

Next, you’ll need the login details of the FTP site:
Host: e.g. sftp.contoso.com
Username
Password

Open a Command Prompt, navigate to the location that contains sftp.exe and type:

sftp username@host -pw password

You’ll probably first be prompted with a message saying ‘The server’s host key is not cached in the registry’ with some details on the fingerprint. If you’re sure you’re connecting to the right server, you can say ‘y’ to ‘Store key in cache’. Once saved, you won’t be prompted for this on the same computer/user.

At this stage, we’re just making sure you can sign in and get past the key stage. If this works, you’ll now need to work on a batch file to pass through all the commands you want to do.

In this example, I’ll be going into a folder and uploading a file. Open notepad and type your commands, which you can first test in your active connection:

cd inbound
mput filename.csv
quit

Pretty simple stuff. Save your notepad file (we’ll call it batchfile.txt), and if you haven’t already disconnected from your SFTP session, do so with the ‘quit’ command.

Connect back to the SFTP site, but this time we’ll specify the batch file to rin after connecting:

sftp username@host -pw password -b batchfile.txt -batch

I’ve also added -batch on the end to specify it’s an automated batch job – this will cause SFTP to exit on a prompt, rather than be running forever waiting for an input. You can try without -batch first if you want to test and see the prompts, but you’ll need to run this command manually rather than triggering from a Scheduled Task.

If this works as expected, great! You can automate the SFTP task – the final step is to schedule it to run, which I usually use the native Scheduled Tasks in Windows to do.

If your scheduled task is running under a different account than what you tested with, then you’ll need to do that initial host key saving – easiest way is to launch Command Prompt as that user, and connect to the FTP site.

Default Printer At First Logon via Group Policy

Deploying a network printer via Group Policy is pretty easy. In Group Policy Management Editor, you go to User Configuration > Preferences > Control Panel Settings > Printers and right click to create a new Shared Printer. Configure the options which are pretty straight forward.

Something doesn’t go right though, if you use the option ‘set this printer as the default printer’. The printer won’t actually be set as default for the first login. As it’s set to Update though, this will get fixed next time Group Policy runs.

However, if you have the Action set to ‘Create’, it only gets one chance to set the default printer – at the time of creation. That fails, and it doesn’t get a chance to set the default printer again.

Why does it fail to set the default printer at first logon? You’ll see an event viewer application error like this:

The user ‘HP Printer’ preference item in the ‘Define Printers {XXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX}’ Group Policy object did not apply because it failed with error code ‘0x80070709 The printer name is invalid.’ This error was suppressed.

There’s a clear Microsoft Support Article that explains why – in summary, Windows isn’t ready yet to change something on the printer between the time it creates the printer, and then tries to make it default as they’re two separate actions.

However, we can work around this by deploying a registry entry that sets the default printer. This 11 year old article is still correct in that it shows the registry value to change:

HKEY_CURRENT_USER\Software\Microsoft\Windows NT\CurrentVersion\Windows

REG_SZ - Device
Value - \\adamfowlerit\printer,winspool,Ne04:e

Setting this via registry as an ‘Apply once and do not reapply’ with any other logic matching your printer deployment policy, should end up with the printer as a default on first logon.

This is a problem that’s been around for many years, but the first time I’ve hit it!

Also, if you’re wondering what the ‘Ne04’ part means, it seems to be some sort of counter which goes up for each time you install a printer.

How To Grep in PowerShell

For those who have lived in the Linux/Unix command line, the ‘grep‘ command is a commonly used way of finding something that you want in a chunk of data.

Øyvind Kallstad did a great writeup of comparing a bunch of ways to use PowerShell instead of grep which is worth reading.

The article covers a bunch of scenarios, and is centered around starting with the ‘grep’ command and working with it. However, there’s the other common use case of running a different command, then piping those results to grep to search for something.

This blogpost was triggered by Janet who asked me this fair question:

As with poor cute cats, there’s more than one way to skin PowerShell.

I had to do some research and asking around on this, because normally I’d filter out the property of the object I was looking at, and work with that. Using the get-process example:

get-process | where ProcessName -like "*foo*

That works, but it’s still a lot clunkier than what a grep user would expect. An easier way would be to use the ‘findstr‘ program (which also has a bunch of useful swtiches):

get-process | findstr foo

I say program because ‘findstr’ is not a PowerShell cmdlet, but it’s still native to Windows and works perfectly fine. It’s case sensitive though, so you need to use -i for case insensitive results.

That’s great for simple stuff, but we’re sort of breaking what PowerShell does. You’re no longer dealing with a standard PowerShell object, so further piping and processing won’t really work.

The ‘proper’ PowerShell way would be to use the ‘Where-Object’ command:

Get-Process | Where-Object {$_ | Select-String "foo"}

A bit longer, but you can shorten ‘Where-Object’ to ‘Where’. Although more involved, it’s good to get into the habit of doing it this way, so when you’re piping this to the next command, it still says as a standard object that can be read and manipulated.’

(Update 24th Feb 2017) As Steve_N points out in the comments section, there’s a much shorter way of doing this:

ps *foo*

That’s it. Many PowerShell commands have inbuilt aliases, including ‘get-process’. You can see what this is with the command ‘get-alias -definition get-process’

This shows that ‘gps’ and ‘ps’ are both aliases to the command  ‘get-process’. You can also create your own aliases with the ‘set-alias‘ command.

The ‘*foo*’ part works because the command assumes the -name switch has been used, which lets you define what criteria to search and show in the ProcessName field. This is the same way that many commands don’t need the -identity switch used, because it’s written to assume you’re going to tell it what identity/username/upn to work with.

This can also be piped to something else, so it’s a winner. It’s less ideal for scripts though, because it’s much harder to read, and you can’t assume that everyone will know the short alias of a full command.

Also note that this isn’t grep related at all, so part of the answer to the original question is that you may not even need grep or select-string as it adds unnecessary overhead of getting data and parsing it, whereas this updated example filters the data as it’s obtained.

(Update ends)

PowerShell isn’t a Linux/Unix command line, but Microsoft have incorporated many of the concepts from bash. If you still can’t bear to use PowerShell on Windows, there’s always the Linux Bash Shell on Windows.

Thanks again to Steve Mclnerey for the grep advice :)

Windows 10 – Time To Get On Board

Windows 10 has been publicly available since 29th July 2015. Since then, Microsoft have been encouraging users to upgrade in many ways – consumers had a year window to upgrade from Windows 7/8/8.1 for free, along with Windows Update prompts reminding consumers that they can do so.

There’s always going to be complaints with any new operating system, but the in-place upgrade process has been the best yet from Microsoft. Gone are the days when any IT professional would strongly avoid it, it’s a much more stable and revertable method.

The upgrade has been optional, but we’re now getting much closer to being forced to go Windows 10 (not that I think this is a bad thing). The two big ways this is happening are:

New PCs with Windows 7 or 8.1 are going to be much less common come November 1, 2016. The top OEM vendors won’t be allowed to do this anymore (E.g. Lenovo, HP, Dell). You could still go to a whitebox builder and buy an OEM version of Windows 7, it just won’t be a pre-packaged option anymore. Windows 7 is very old now, and it’s unrealistic to expect Microsoft as well as all the hardware manufacturers to continue supporting it with new drivers.

The other main driver is Intel’s 7th generation of i series chip, Kaby Lake. This has already been released and seen in some laptops, with desktop CPUs due to be released early 2017. Microsoft is drawing a line in the sand and saying there will be no support at all if you’ve got this new CPU. I have yet to get my hands on a device with these new CPUs to try, so it will be interesting to see if anything breaks with this combination of OS and CPU.

Windows 7 has had a very good run, with great reasons; but the vast improvements that have taken us to Windows 10 (not to mention the better security architecture), as well as internal support for cloud services means this is the way of the future.

If you haven’t started the transition to Windows 10 it’s time to get planning, before you hit the above roadblocks and haven’t put the planning and preparation into the change.
