Migrating Phone System from Skype for Business to Microsoft Teams

I thought I’d document a few lessons learned in this migration. The migration was from Skype for Business Server 2015 and Skype for Business 2016 clients with Enterprise Voice, moving users across to Microsoft Teams.


The steps to migrate a user for me were:

  1. Add user to AD Group “Azure AD Licensing Telstra Calling for Office 365” as this allocates a Telstra Calling for Office 365 license. These licenses are bought from https://marketplace.telstra.com/ and feed into Microsoft 365. I believe this is unique to Australia.
  2. From Skype for Business Server Management Shell:
    $cred=Get-Credential
    $url="https://adminau1.online.lync.com/HostedMigration/hostedmigrationService.svc" (different links here for different countries)
    Move-CsUser -Identity userupn@contoso.com –Target sipfed.online.lync.com -MoveToTeams -Credential $cred -HostedMigrationOverrideUrl $url

    set-csuser -identity userupn@contoso.com -LineURI $null
  3. Form a machine with the Teams PowerShell Module installed:
    $Session = New-CSOnlineSession -OverrideAdminDomain yourdomain.onmicrosoft.com
    Import-PSSession $session –AllowClobber
    Set-CsOnlineVoiceUser -Identity userupn@contoso.com -TelephoneNumber 61812341234
    Grant-CsTeamsUpgradePolicy -PolicyName UpgradeToTeams -Identity userupn@contoso.com
  4. Configure call forwarding in Gateway (Pilot Users only that were being given a new number out of our normal number range)

EHR Error on Teams Portal

We can’t get details of EHR usage. Please try again. If you continue to have problems, contact Microsoft customer support.

Seeing this error everywhere on the Teams Admin portal, unsure what the cause/fix is yet. It ended up disappearing by itself after a few weeks *shrug* – you’ll see this theme is common around portal errors.


Dial Plans error


We can’t get the effective dial plan so the dial plan can’t be tested.

Going into any Dial Plan brings up this admin portal error, as well as trying to run a Test Dial plan test:

Something went wrong while testing this phone number. If you continue to have problems, contact Microsoft customer support.

This problem was another portal issue – logged a case which Microsoft confirmed was at their end, and a few weeks later they’d resolved it.


Create Resource Account error

We can’t save changes to ___

When creating a Resource Account used for Auto Attendant or Call queues, I was getting a very unhelpful error. I believe this is because I’m running in hybrid mode, so Teams can’t create an account on my primary domain – changing the domain to @contoso.onmicrosoft.com then let me create the Resource Account.

This problem also disappeared later and now I can create accounts on my primary domain – put it down to another portal issue.


Desk Phones requiring PIN

Phones would be registered in Intune, because they’re running Android – and that means any ‘all user’ Android policy would apply.

I’ve since created Dynamic Device Groups and filtered by DeviceModel and DeviceOSType – only testing the Poly CCX500 at this stage, but will add more models as we get them. Also filtering by OStype which is not really necessary, but does make sure it’s only Android devices affected.

(device.deviceModel -eq "CCX500") and (device.deviceOSType -eq "Android")

If you use a test account 20 times, that account will hit its device limit in azure and get locked out.


Skype for Business users unable to call Teams users

Early in migration, we tested interoperability between the two platforms, as it wasn’t going to be an overnight company wide migration. A Skype for Business user trying to call a migrated to Teams user would instead get diverted elsewhere. This was because we had Unassigned Number range rules in place, that were designed to send calls somewhere if it wasn’t allocated to anyone. Removing these rules immediately fixed this issue.


Home Screen on Desk Phones Laggy

The default experience if the phone supports it, is to show a home screen. More details on what the Home Screen is here. This is in CsTeamsIPPhonePolicy with the default value ‘AllowHomeScreen’ set to ‘EnabledUserOverride’. Changing this to Disabled via the PowerShell command:

set-CsTeamsIPPhonePolicy -allowhomescreen Disabled

removed this. I like the idea of the Home Screen, but not at the cost of a fast functioning phone vs a slow one.

I later found out this is due to the 1GB RAM on some devices, and Teams now (at the time of writing) uses > 1GB RAM, and then the Home Screen uses even more RAM. Trying a phone model with 2GB RAM this all worked perfectly.

I believe this is also fixed now, but it took Microsoft about 5 months to resolve.


New Desk Phones not signing in

Testing the Poly CCX500 model, some wouldn’t sign in to Teams out of the box. As soon as I tried to sign in, they’d say:

‘Error Could not sign in. You will need to sign in again. If you see this message again, please contact your company support. OK’

I spent so long on this, unsuccessfully trying to update the firmware via USB etc. In the end, turning off the ‘DHCP Time’ setting under ‘Device Settings’ made it work – I assume it had some problems contacting a NTP server (settings appeared correct in the DHCP scope of the phone). Someone else found the same issue here, but this was due to the phone running a very old v1 firmware. This shouldn’t affect most people, but worth noting.


Device Limit Reached – Intune Company Portal App

Device limit reached – You have added the maximum number of devices allowed by your company support. Plesae remove a device from the Azure portal or get help from your company support.

There’s a limit to the amount of devices you can register for the Intune Company Portal app.

To fix this, yes you’ll need to remove a device attached to your account. This is not done via Outlook for Web, where you can remove devices – that’s purely for Outlook. It’s also not done via https://myaccount.microsoft.com/device-list as it’s not removing it from Azure.

As per Microsoft Documentation , there’s Intune device limits, and Azure device limits. Intune / EndPoint Manager has a maximum of 15 devices, where Azure has a default of 20, but can be changed to a few different values, including ‘unlimited’.

Intune / Endpoint Manager Device Limits
Azure Device Limits

To remove devices from a user, and admin should use Azure Active Directory and go to Users > Find the user > then under Manage, choose ‘Devices’. Any old device (check by the activity date) can be selected and deleted.

After removing enough devices here, you should be able to register the new device via the Intune Company Portal app again – and in my testing, this was next to instant.

Microsoft Forms now has a shorten URL option

Such a basic thing, but great to see. As per this Forms Uservoice suggestion, Microsoft Forms now has a ‘shorten URL’ option. It’s still rolling out right now (March 2021) but it turned up in my tenants. You’ll find it under the Share menu, and then under ‘Send and collect responses’ :

The tick box is called ‘Shorten URL’:

Before ticking this box, the Forms URL for sharing looks like this:

https://forms.office.com/Pages/ResponsePage.aspx?id=gp6jfCyryEOFjHcqjfOQaicaufj5P4hCmrpZg_pruFhUNUFYSUlQMFEwRjVRNkZPUDBLOFYwUUtRVy4u

After ticking the box, it takes about a second or so to update, then looks like this:

The resulting link is of course, shorter. It also looks a lot nicer:

https://forms.office.com/r/Qca3qTjcMu

It’s nice to see a much more usable URL come out of Microsoft Forms, and still on the forms.office.com domain without having to resort to a third party URL shortener service.

Impersonation Protection delivers emails to Junk Folder

Impersonation Protection in Microsoft Defender for Office 365 is part of the Anti-phishing policies, designed to take action if an external email comes in with a match, or near match, to the display name of an employee.

The actions you can take when a match is made are:

  • Redirect message to other email addresses
  • Move message to the recipient’s Junk Email folders
  • Quarantine the message
  • Deliver the message and add other addresses to the Bcc line
  • Delete the message before it’s delivered
  • Don’t apply any action

What I wanted to do, was deliver the message and add other addresses to the bcc line. This could be used to send a copy of the email to helpdesk for investigation, as Impersonation Protection tends to get a lot of false positives from services that like to use people’s actual names from emails they generate, or from people using a personal account to email other employees.

What I found was that the action was applied, but the email was then delivered to the Junk Email folder. If I wanted that to happen, I would have selected the ‘Move message to the recipient’s junk email folders’ option. After logging a case with Microsoft, I found out why.

Any time an email is detected as an Impersonation Protection, and the mail is still allowed to flow through, it will set the header as SCL 5. As per Office 365 standards, this will deliver the email to the recipient’s junk mail folder.

It makes the choices on what actions to take in the Impersonation Protection settings rather misleading; but there is one option that’s still reasonable – Quarantine the message. This should trigger a fairly quick quarantine digest to the recipient for review, allowing them to review and decide if it should be released. If released, it will then deliver to the Inbox rather than Junk Mail.

How to Backup Office 365 Mailboxes with Altaro

Backing up mailboxes in Exchange Online as a part of the Office 365 or Microsoft 365 suite is always a debated topic – some will argue that Microsoft have enough redundancy and backups in their own environments so you don’t need a third party solution and you’ll always be able to get your data back. However, this hasn’t been proven yet (thankfully) in a real world event where mailbox data has been lost by Microsoft. It also doesn’t cover scenarios where there’s outages, account problems or other connectivity problems that can delay your access to your cloud based data. Is it a risk each company will need to decide if it’s worth an investment into reducing.

Altaro asked me to have a look at their product – Altaro Office 365 Backup – to provide a quick run-through on setting it up and seeing what it does. Their solution is fully cloud based, so you don’t need any extra hardware to get going. You can set up a 30 day free trial here. Once signed up, here’s what to do:

After logging in from the link you’ll be emailed, you’ll be presented with this screen:

The wizard here will take you through the setup required, starting with a Company Name and your domain configured in Office 365 (which you can get from https://admin.microsoft.com/Adminportal/Home#/Domains) – I had to use my primary:

Next, you’ll need to grant access for Altaro to be able to access data in your tenant, which makes sense since you want them to back it up:

Following the links you’ll get the standard window advising you what permissions you’re granting and to whom:

If it worked, a successful message will show and you can go back to the setup wizard:

After doing this three times, you can go to the next step where you can choose which users to back up – which as it says, will be this data: “Office 365 User Backups consist of Emails, Calendars & Contacts within Mailboxes and Files stored within OneDrive accounts.”, then “SharePoint Backups consist of Files stored within SharePoint Document Libraries.”

If it all goes well, you’ll then get to the final screen showing a successful setup:

That’s it – backup has been set up. Of course your data won’t be in there instantly, the first backup happens over 24 hours, and then up to 4 times a day ongoing. You can choose if new users are automatically added to backup plans or not, which should turn this into a set and forget backup system.

Set and forget only works if you’re alerted around issues, which is possible in the Alert Settings – you can choose what sort of alerts you receive, such as if a backup job failed:

Restoring is also an easy process – for example if you want to restore an entire mailbox, the Mailbox Restore wizard will take you through the steps and ask where you want to restore – onto that user’s mailbox, another user’s mailbox, an Outlook PST file, or a ZIP file containing each mail item as an individual file:

You can also use the Granular Restore option, to search and restore particular items rather than entire mailboxes and accounts. The granular restore has the same options as the full restore for destinations, so there’s a lot of flexibility based on what you’re after:

If you can’t find what you’re looking for, the ‘Advanced Search’ option lets you define what you’re looking for:

Pricing for Office 365 Backup by Altaro is available at https://www.altaro.com/office-365-backup/#faqs and is a per user, per type (either mailbox or mailbox + OneDrive + SharePoint) model. This also includes 24/7 support and unlimited storage for backups.

After setting this up and trying out all the options, I’m confident in saying this is as good as you could hope for, from a turn-key solution. Setup is literally a few minutes, there’s no software to install anywhere and no infrastructure requirements. The data Altaro backs up is held forever (yes, infinite retention!) assuming you still have a valid subscription. The data is stored in Microsoft Azure, but only in West Europe at the time of writing – so if you have data sovereignty requirements, you’ll need to assess this.
